McCormick Intl CX95
|
|
| Production | |
| Manufacturer | McCormick Intl |
| Utility tractor | |
| Built in Doncaster, England | |
| McCormick Intl CX95 Engines | |
| Perkins 4.0L 4-cyl diesel | |
| Perkins 4.4L 4-cyl diesel | |
 Engine details ... |
| McCormick Intl CX95 Transmissions | |
| 24-speed partial power shift | |
| 8-speed synchro shuttle | |
| 16-speed partial power shift | |
 Transmission details ... |
| McCormick Intl CX95 Power | |
| Engine (net) | 90 hp 67.1 kW |
| Engine | 90 hp 67.1 kW |
| PTO (claimed) | 74 hp 55.2 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| ROPS. Cab optional. | |
| Photos | |
| No photos of the McCormick Intl CX95 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 41 gal 155.2 L |
| Hydraulic system | 9.1 gal (2WD) 34.4 L |
| 9.7 gal (4WD) 36.7 L | |
| Hydraulics | |
| Type | open center |
| Capacity | 9.1 gal (2WD) 34.4 L |
| 9.7 gal (4WD) 36.7 L | |
| Pump flow | 15.85 gpm 60.0 lpm |
| Tractor hitch | |
| Rear lift | 8,543 lbs 3875 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540@2000 |
| 1000@2000 | |
| Dimensions & Tires | |
| Wheelbase | 92.9 inches 235 cm |
| Weight | 8312 to 8467 pounds |
| Front tire | 10.00-16 |
| Rear tire | 16.9R34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 65 |
| Battery volts | 12 |
| References | |
 | |
| CX Series published in 2006, by McCormick |
