John Deere 8430
|
|
| Production | |
| Manufacturer | John Deere |
| Row-Crop tractor | |
| Built in Waterloo, Iowa, USA | |
| John Deere 8430 Engine | |
| John Deere 9.0L 6-cyl diesel | |
 Engine details ... |
| John Deere 8430 Transmission | |
| 16-speed full power shift | |
 Transmission details ... |
| John Deere 8430 Power | |
| Engine (gross) | 305 hp 227.4 kW |
| Engine (max) | 330 hp 246.1 kW |
| PTO (claimed) | 250 hp 186.4 kW |
| Drawbar (tested) | 223.57 hp 166.7 kW |
| PTO (tested) | 289.26 hp 215.7 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | 4x4 Independent Link Suspension MFWD 4WD (ILS) |
| 4x4 MFWD 4WD | |
| Power steering | |
| Wet disc brakes | |
| CommandView cab standard. | |
| Photos | |
 | |
 John Deere 8430 photos... | |
| Capacity | |
| Fuel | 180 gal 681.3 L |
| Hydraulic system | 9.5 gal 36.0 L |
| 14.5 gal (with aux reservoir) 54.9 L | |
| Hydraulics | |
| Type | closed center PFC |
| Capacity | 9.5 gal 36.0 L |
| 14.5 gal (with aux reservoir) 54.9 L | |
| Valves | 3 to 5 |
| Pump flow | 31.7 gpm 120.0 lpm |
| Total flow | 44 gpm 166.5 lpm |
| 60 gpm (optional) 227.1 lpm | |
| Tractor hitch | |
| Rear Type | III |
| IV (optional) | |
| Rear lift | 17,300 lbs 7847 kg |
| 18,300 lbs (optional) 8300 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 |
| 540/1000 (optional) | |
| Engine RPM | 540@1817 |
| 1000@2000 | |
| Dimensions & Tires | |
| Wheelbase | 118.9 inches (ILS) 302 cm |
| 120.1 inches (MFWD) 305 cm | |
| Weight | 24825 to 25791 pounds |
 Full dimensions and tires ... | |
| 8430 Serial Number Location | |
 | |
| Rear of tractor near PTO |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 200 |
| Batteries | 2 |
| Battery CCA | 925 |
| Battery volts | 12 |
| References | |
 | |
| 8030 Series 2007 Updates published by John Deere |
