John Deere 8430 Tests
|
|
| Tractor Tests | |
| OECD 1873: diesel PowerShift 4WD | |
| OECD 1874: diesel IVT 4WD |
| OCED Tractor Test 1873 | |||
| |||
| OCED Tractor Test 1873 | |
| Diesel PowerShift 4WD March 14 - April 5, 2006 Link: OCED Tractor Test 1873 file | |
| PTO performance | |
| Max power | 289.26 hp 215.7 kW |
| Fuel use | 14.9 gal/hour 56.4 l/hour |
| Power at rated engine speed | 253.05 hp 188.7 kW |
| Fuel use | 13.6 gal/hour 51.5 l/hour |
| Power at rated PTO speed | 273.44 hp 203.9 kW |
| Fuel use | 14.4 gal/hour 54.5 l/hour |
| Drawbar performance | |
| Max power | 223.57 hp 166.7 kW |
| Fuel use | 13.4 gal/hour 50.7 l/hour |
| Gear 10 used for power test. | |
| Max pull | 24028 lbs 10899 kg |
| Gear 5 used for pull test. | |
| OCED Tractor Test 1874 | |||
| |||
| OCED Tractor Test 1874 | |
| Diesel IVT 4WD March 16 - April 5, 2006 Link: OCED Tractor Test 1874 file | |
| PTO performance | |
| Max power | 283.18 hp 211.2 kW |
| Fuel use | 15.0 gal/hour 56.8 l/hour |
| Power at rated engine speed | 253.01 hp 188.7 kW |
| Fuel use | 17.9 gal/hour 67.8 l/hour |
| Power at rated PTO speed | 272.59 hp 203.3 kW |
| Fuel use | 14.8 gal/hour 56.0 l/hour |
| Drawbar performance | |
| Max power | 211.26 hp 157.5 kW |
| Fuel use | 13.6 gal/hour 51.5 l/hour |
| Pull at 7.5 kph | |
| Max pull | 34,671 lbs 15726 kg |
| Pull at 3.6 kph | |
