John Deere 8230


John Deere 8230 tractor photo
2006 - 2009
8030 Series
Row-Crop tractor
Series map:
8130
8230
8330
225.0hp
245.0hp
275.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Variants
8230row-crop tractor
8230Tcrawler tractor
John Deere 8230 Engine
John Deere 9.0L 6-cyl diesel
Engine details ...
John Deere 8230 Power
Engine (gross)245 hp
182.7 kW
Engine (max)265 hp
197.6 kW
PTO (claimed)200 hp
149.1 kW
Drawbar (tested)180.35 hp
134.5 kW
PTO (tested)232.51 hp
173.4 kW
Performance test details ...
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
CommandView cab standard.
Capacity
Fuel180 gal
681.3 L
Hydraulic system9.5 gal
36.0 L
 14.5 gal (with aux reservoir)
54.9 L
Hydraulics
Typeclosed center PFC
Capacity9.5 gal
36.0 L
 14.5 gal (with aux reservoir)
54.9 L
Pressure2098 psi
144.7 bar
Valves3 to 5
Pump flow31.7 gpm
120.0 lpm
Total flow44 gpm
166.5 lpm
 60 gpm (optional)
227.1 lpm
Tractor hitch
Rear TypeIII/IIIN
 IVN/III (optional)
Rear lift (at 24"/610mm)12,400 lbs
5624 kg
 15,200 lbs (optional)
6894 kg
 17,300 lbs (optional)
7847 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000
 540/1000 (optional)
Engine RPM540@1817
 1000@2000
Dimensions & Tires
Wheelbase118.9 inches (ILS)
302 cm
Weight23747 to 25147 pounds
Full dimensions and tires ...
8230 Serial Number Location
John Deere 8230 serial number location
Rear of tractor.
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Batteries2
Battery CCA925
Battery volts12
References
8230 references literature
8030 Series 2007 Updates published by John Deere
