Fendt Farmer 260S
|
|
| Production | |
| Manufacturer | Fendt |
| Row-Crop tractor | |
| Variants | |
| 260S | 2WD |
| Fendt Farmer 260S Engine | |
| KHD 3.1L 3-cyl diesel | |
| Fuel tank | 15.9 gal 60.2 L |
 Engine details ... | |
| Fendt Farmer 260S Transmissions | |
| 21-speed | |
| 21-speed shuttle | |
 Transmission details ... |
| Fendt Farmer 260S Power | |
| Engine | 59 hp 44.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic drum brakes | |
| Cab standard with heat. Air-conditioning optional. |
| Photos | |
| No photos of the Fendt Farmer 260S are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2611 psi 180.0 bar |
| Pump flow | 10.8 gpm 40.9 lpm |
| Tractor hitch | |
| Rear lift | 6151 lbs 2790 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/750/1000 |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 80.7 inches 204 cm |
| Weight | 5556 to 6107 pounds |
| Front tire | 7.50-18 |
| 2WD Rear tire | 16.9R28 |
 Full dimensions and tires ... | |
| Fendt Farmer 260S attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| Charging amps | 55 |
| Charging volts | 14 |
| Battery volts | 12 |
| Battery AH | 88 |
| References | |
 | |
| Farmer 250S 260S 280S published in 1996, by Fendt | |
| Innovations for 1988 published by Fendt |
