SAME Krypton F 90
|
|
| Production | |
| Manufacturer | SAME |
| Agricultural Crawler tractor | |
| SAME Krypton F 90 Engine | |
| SAME 4.0L 4-cyl diesel | |
| Fuel tank | 19.8 gal 74.9 L |
 Engine details ... | |
| SAME Krypton F 90 Transmissions | |
| 16-speed shuttle | |
| 16-speed creeper | |
 Transmission details ... |
| SAME Krypton F 90 Power | |
| Engine (gross) | 85.8 hp 64.0 kW |
| Engine (net) | 81.8 hp 61.0 kW |
| Mechanical | |
| Drive | crawler |
| Two-post mid-mount folding ROPS. | |
| Photos | |
| No photos of the SAME Krypton F 90 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 14.8 gpm 56.0 lpm |
| Total flow | 22.2 gpm 84.0 lpm |
| Tractor hitch | |
| Rear lift | 6615 lbs 3000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/540E |
| Dimensions & Tracks | |
| Wheelbase | 65 inches 165 cm |
| Weight | 8930 lbs 4050 kg |
| 12.2-inch tracks | |
 Full dimensions and tracks ... | |
| References | |
 | |
| Krypton F 80-90-100 published in 2005, by SAME |
