SAME Saturno 80
|
|
| Production | |
| Manufacturer | SAME |
| Row-Crop tractor | |
| SAME Saturno 80 Engine | |
| SAME 4.2L 4-cyl diesel | |
| Fuel tank | 21.1 gal 79.9 L |
 Engine details ... | |
| SAME Saturno 80 Transmissions | |
| 8-speed partially synchronized | |
| 14-speed creeper | |
 Transmission details ... |
| SAME Saturno 80 Power | |
| Engine | 80 hp 59.7 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| 2WD Steering | manual |
| 4WD Steering | power |
| Mechanical dry disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| Four-post ROPS. | |
| Photos | |
 | |
 SAME Saturno 80 photos... | |
| Hydraulics | |
| Pump flow | 6.3 gpm 23.8 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 6174 lbs 2800 kg |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Clutch | mechanical dry disc |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 92.52 inches 235 cm |
| Weight | 6150 to 6746 pounds |
| Front tire | 7.50-18 |
| 2WD Rear tire | 16.9/14-34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Saturno 80 Synchro published in 1978, by SAME |
