Farmtrac 520
| | Utility tractor | | Escorts built |
|
| Production |
| Distributor | Farmtrac
|
| Manufacturer | Escorts
|
| Utility tractor |
| Built in Faridabad, India |
| Farmtrac 520 Power |
| Engine | 52 hp
38.8 kW
|
| PTO (claimed) | 46 hp
34.3 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Two-post ROPS. |
| Hydraulics |
| Pump flow | 9 gpm
34.1 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Rear lift | 2645 lbs
1199 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| Electrical |
| Ground | negative
|
| Charging amps | 36
|
| Battery CCA | 600
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 13, 2021 |
