UTB/Universal 300


UTB/Universal 300 tractor photo
1980 - 1991
Utility tractor
Production
ManufacturerUTB/Universal
Utility tractor
Built in Brasov, Romania
Original price was $13,000 in 1991
Variants
300DTC4WD
UTB/Universal 300 Engine
UTB 1.6L 2-cyl diesel
Fuel tank14.3 gal
54.1 L
Engine details ...
UTB/Universal 300 Power
Engine27.5 hp
20.5 kW
PTO (claimed)26 hp
19.4 kW
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Steeringhydrostatic power
Dry band brakes
Open operator station.
Photos
No photos of the UTB/Universal 300 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow6.6 gpm
25.0 lpm
Tractor hitch
Rear TypeII/I
Controlposition and draft control
Rear lift2650 lbs
1202 kg
Power Take-off (PTO)
Rear PTOlive
Rear PTO Type540 (1.375)
Engine RPM540@1967
Dimensions & Tires
2WD Wheelbase71.1 inches
180 cm
4WD Wheelbase68.1 inches
172 cm
Weight3508 to 4144 pounds
Front tire6.00-16
2WD Rear tire14.9-28
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
300 references literature
U-300 U-340 published by Universal
Loaders published in 1987, by Universal
