Tractors > AGCO Allis > 9785

AGCO Allis 9785 Tests



AGCO Allis 9785 tractor photo
1998 - 2001
9700 Series
Row-Crop tractor
Series map:
9775
9785
222.2hp*
250.0hp*
*Estimated engine power for comparison only.
OCED Tractor Test 1795
9785 fuel use from test 355
OCED Tractor Test 1795
Cummins diesel 18-speed 4WD
May 2 - 18, 2001
Link: OCED Tractor Test 1795 file
PTO performance
Max power233.39 hp
174.0 kW
Fuel use14.2 gal/hour
53.7 l/hour
Power at rated engine speed227.95 hp
170.0 kW
Fuel use14.4 gal/hour
54.5 l/hour
Power at rated PTO speed233.39 hp
174.0 kW
Fuel use14.2 gal/hour
53.7 l/hour
Drawbar performance
Max power200.61 hp
149.6 kW
Fuel use14.5 gal/hour
54.9 l/hour
Gear 11 used for power test.
Max pull18284 lbs
8293 kg
Gear 7 used for pull test.
