Deutz-Fahr DX 6.50
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Row-Crop tractor | |
| Deutz-Fahr DX 6.50 Engine | |
| Deutz 6.1L 6-cyl diesel | |
| Fuel tank | 40 gal 151.4 L |
| 66 gal*With optional tank. 249.8 L | |
 Engine details ... | |
| Deutz-Fahr DX 6.50 Transmissions | |
| 24-speed two-speed power shift | |
| 32-speed two-speed power shift | |
 Transmission details ... |
| Deutz-Fahr DX 6.50 Power | |
| Engine | 137 hp 102.2 kW |
| PTO (claimed) | 120 hp 89.5 kW |
| Drawbar (tested) | 101.36 hp 75.6 kW |
| PTO (tested) | 122.06 hp 91.0 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| OPTITRAC front | |
| Power steering | |
| Hydraulic dry disc brakes | |
| Mastercab standard with air-conditioning. | |
| Photos | |
| No photos of the Deutz-Fahr DX 6.50 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2538 psi 175.0 bar |
| Valves | 1 to 3 |
| Pump flow | 24 gpm 90.8 lpm |
| Tractor hitch | |
| Rear Type | III |
| Rear lift (at ends) | 14330 lbs 6500 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2192 |
| 1000@2214 | |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 105.8 inches 268 cm |
| 4WD Wheelbase | 106.4 inches 270 cm |
| Weight | 11243 to 12081 pounds |
| Front tire | 11.00x16 |
| 2WD Rear tire | 18.4x38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| DX4.70-DX6.30-DX6.50-DX7.10 published in 1984, by Deutz-Fahr | |
| DX6 published in 1983, by Deutz-Fahr |
