Fiat 600
|
|
| Production | |
| Manufacturer | Fiat |
| Utility tractor | |
| Variants | |
| 600 | 2WD |
| 600DT | 4WD |
| Fiat 600 Engine | |
| Fiat 3.5L 4-cyl diesel | |
| Fuel tank | 14.3 gal 54.1 L |
 Engine details ... | |
| Fiat 600 Transmissions | |
| 8-speed gear | |
| 12-speed creeper | |
 Transmission details ... |
| Fiat 600 Power | |
| Engine | 60 hp 44.7 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Steering | manual |
| Steering | power OptOptional |
| Band brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Fiat 600 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 5.8 gpm 22.0 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and draft control |
| Rear lift | 3080 lbs 1397 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1970 |
| Dimensions & Tires | |
| 2WD Wheelbase | 81.5 inches 207 cm |
| 4WD Wheelbase | 83.1 inches 211 cm |
| Weight | 4620 to 5137 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 14.9/13-30 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| 600 published in 1971, by Fiat | |
| 600 Compatto published in 1971, by Fiat | |
| 600 DT published in 1971, by Fiat |
