Cub Cadet 5234D Transmission


Cub Cadet 5234D tractor photo
2004 - 2008
5000 Series
Sub-Compact Utility tractor
Series map:
5254
5234D
5264
25.0hp
23.0hp
26.0hp
Transmission
Typehydrostatic
Gearsinfinite forward and reverse (2-range)
Oil capacity20 qts
18.9 L
Oil type
Cub Cadet Drive System Fluid Plus
Oil change200 h
Two-range hydrostatic transmission with right-hand forward and reverse pedals. Tractor must be stopped to shift ranges.
Speeds
5234D  hydrostatic speeds
