John Deere 4230 Low Profile


John Deere 4230 Low Profile tractor photo
1973 - 1977
Generation II Series
Orchard/Vineyard tractor
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Built in Waterloo, Iowa, USA
Total built90
Variants
4230row-crop
4230 Hi-Crophigh clearance
4230 LPlow-profile
John Deere 4230 Low Profile Engine
John Deere 6.6L 6-cyl diesel
Fuel tank37 gal
140.0 L
Engine details ...
John Deere 4230 Low Profile Transmissions
16-speed partial power shift and synchronized
8-speed full power shift
8-speed
Transmission details ...
John Deere 4230 Low Profile Power
PTO (claimed)100 hp
74.6 kW
Mechanical
Two-wheel drive
Final drivesplanetary
Differential lockhydro-mechanical rear
Power steering
Differential hydraulic wet disc brakes
Open operator station.
Photos
No photos of the John Deere 4230 Low Profile are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Tractor hitch
Rear TypeII
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase97.5 inches
247 cm
Front tire9.5L-15
Rear tire18.4-30
Full dimensions and tires ...
4230 Low Profile Serial Number Location
John Deere 4230 Low Profile serial number location
Serial number plate on the rear of the John Deere 4230, above the PTO shaft.
Electrical
Groundnegative
Charging systemalternator
Batteries2
Battery volts6
References
4230 Low Profile references literature
Tractors 80 to 150 hp published in 1975, by John Deere
Making you next tractor a John Deere has traditionally been a good investment published in 1975
