John Deere 4710


John Deere 4710 tractor photo
2002 - 2004
4000 Ten Compact Series
Compact Utility tractor
Series map:
4610
4710
42.8hp
46.3hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
John Deere 4710 Transmissions
12-speed power shuttle
hydrostatic
Transmission details ...
John Deere 4710 Power
Engine (gross)46.3 hp
34.5 kW
Hydro PTO (claimed)38.5 hp
28.7 kW
Gear PTO (claimed)40 hp
29.8 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Power steering
Wet disc brakes
Platform with two-post folding ROPS.
Capacity
Fuel12.5 gal
47.3 L
Hydraulic system9.7 gal
36.7 L
 9.2 gal (hydrostatic)
34.8 L
Front axle5.2 qts
4.9 L
Hydraulics
Typeopen center
Capacity9.7 gal
36.7 L
 9.2 gal (hydrostatic)
34.8 L
Pressure2500 psi
172.4 bar
Pump flow10.6 gpm
40.1 lpm
Total flow15.9 gpm
60.2 lpm
Steering flow5.3 gpm
20.1 lpm
Tractor hitch
Rear TypeI
Rear lift2500 lbs
1134 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear PTO Type540 (1.375)
Engine RPM540@2600
Mid PTOindependent OptOptional
Mid PTO Type2100
Dimensions & Tires
Wheelbase71.5 inches
181 cm
Weight3450 lbs
1564 kg
Front tire6.00-16
Rear tire13.6-24
Full dimensions and tires ...
John Deere 4710 attachments
72" mid-mount mower deck
blade
front-end loader
backhoe
Attachment details ...
4710 Serial Number Location
John Deere 4710 serial number location
Serial number plate on the right side of the tractor frame, above the front axle.
4710 Serial Numbers
2002170001
2003270001
2004370001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery CCA690
Battery volts12
References
4710 references literature
4000 TEN Series 18 To 48 HP published in 2001, by John Deere
The New John Deere 4000 TEN Series Tractors published in 2002
4000 TEN Series - The tractor redefined published in 2001, by John Deere
4000 TEN Series - Take Command published in 2001, by John Deere
4000 TEN Series Product Information Handbook published in 2003, by John Deere
