CaseIH MXM120 Maxxum
| | 2002 - 2007 |
| Maxxum Series | | Row-Crop tractor |
|
Series map:
MXM120
MXM130
122.0hp
129.0hp
| Production |
| Manufacturer | CaseIH
|
| Row-Crop tractor |
| Built in Basildon, England |
| CaseIH MXM120 Power |
| Engine | 122 hp
91.0 kW
|
| PTO (claimed) | 95 hp
70.8 kW
|
| Drawbar (tested) | 83.0 hp
61.9 kW
|
| PTO (tested) | 104.9 hp
78.2 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Differential hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Capacity |
| Fuel | 75 gal
283.9 L
|
| Hydraulic system | 23.75 gal
89.9 L
|
| Hydraulics |
| Type | closed-center load sensing
|
| Capacity | 23.75 gal
89.9 L
|
| Pressure | 2750 psi
189.6 bar
|
| Valves | 2 to 5
|
| Pump flow | 28 gpm
106.0 lpm
|
| SCV flow | 25 gpm
94.6 lpm
|
| Total flow | 44 gpm
166.5 lpm
|
| Steering flow | 16 gpm
60.6 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | electronic lower-link sensing
|
| Rear lift (at 24"/610mm) | 8,725 lbs
3957 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@1969
|
| | 1000@2120
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 120
|
| Battery CCA | 1300
|
| Battery volts | 12
|
| Battery AH | 176
|
| References |
 |
| MXM Series Maxxum Tractors published in 2004, by Case IH |
