CaseIH D35
| | 2001 - 2006 |
| DX Series | | Compact Utility tractor |
|
Series map:
D35
DX35
35.0hp
35.0hp
| Production |
| Manufacturer | CaseIH
|
| Compact Utility tractor |
| Variants |
| D35 | shuttle
|
| DX35 | hydrostatic
|
| TC35 | similar New Holland model
|
| CaseIH D35 Power |
| Engine (gross) | 35 hp
26.1 kW
|
| PTO (claimed) | 29.6 hp
22.1 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Mechanical wet disc brakes |
| Two-post fixed ROPS. Folding ROPS optional. Optional canopy, soft cab, and radio. |
| Hydraulics |
| Type | open center
|
| Valves | 1 or 2
|
| Pump flow | 9.8 gpm
37.1 lpm
|
| Total flow | 14.9 gpm
56.4 lpm
|
| Steering flow | 5.1 gpm
19.3 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at 24"/610mm) | 2025 lbs
918 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | independent OptOptional
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery CCA | 600
|
| Battery volts | 12
|
| References |
 |
| DX Series Compact Tractors published in 2003, by CaseIH |
| DX Series Farmall Tractors published in 2004, by CaseIH |
| DX Series Farmall Tractors published in 2007, by CaseIH |
| DX Series Farmall Tractors published in 2003, by CaseIH |
| DX Series Farmall Tractors and Integrated Implements published in 2004, by CaseIH |
