John Deere 7420 Transmission


John Deere 7420 tractor photo
2003 - 2007
7020 Series
Row-Crop tractor
Series map:
7320
7420
7520
125.0hp
135.0hp
150.0hp
Transmission options
16-speed partial power shift
24-speed
Transmission
TransmissionJohn Deere PowrQuad
Typepartial power shift
Gears16 forward and reverse
Oil capacity59.2 qts
56.0 L
Four power shift speeds (1-4) in four ranges (A-D) with left-hand reverser.
Speeds
With 20.8-38 rear tires.
7420 PowrQuad partial power shift speeds
Transmission
TransmissionAutoQuad
Gears24 forward and reverse
Transmission
TransmissionInfinitely Variable Transmission (IVT)
Gearsinfinite forward and reverse
available with MFWD only
