John Deere 7320



John Deere 7320 tractor photo
2003 - 2007
7020 Series
Row-Crop tractor
Series map:
7220
7320
7420
110.0hp
125.0hp
135.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
John Deere 7320 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank54.7 gal
207.0 L
Engine details ...
John Deere 7320 Transmissions
16-speed partial power shift
24-speed
Transmission details ...
John Deere 7320 Power
Engine125 hp
93.2 kW
PTO (claimed)105 hp
78.3 kW
Drawbar (tested)93.3 hp
69.6 kW
PTO (tested)117.1 hp
87.3 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic rear
Power steering
Hydraulic wet disc brakes
ComfortGard Cab standard with air-conditioning. Open station with two-post ROPS available.
Photos
No photos of the John Deere 7320 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center PFC
Valves4
Pump flow26.7 gpm
101.1 lpm
Tractor hitch
Rear Type2
Rear lift7450 lbs
3379 kg
 8700 lbs (optional)
3946 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000 (1.375)
Engine RPM540@2143
 1000@2143
Front PTOindependent *Optional. Field conversion kit.
Front PTO Type1000 (6-spline)
 1000 (21-spline)
Engine RPM1000@2185
Dimensions & Tires
2WD Wheelbase112.8 inches
286 cm
4WD Wheelbase104.3 inches
264 cm
Weight13,005 lbs
5899 kg
Front tire14.9R28
Rear tire18.4R38
Full dimensions and tires ...
John Deere 7320 attachments
front-end loader
Attachment details ...
7320 Serial Numbers
Location:On the main tractor frame, right side, above the front axle.
20031001
200410001
200530001
200645001
200760001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps115
 150
Battery CCA850
Battery volts12
References
7320 references literature
Get around-the-clock performance with the new 7020 Series Tractors published in 2003, by John Deere
High-Crop and High-Clearance Tractors published in 2004, by John Deere
