John Deere 3120


John Deere 3120 tractor photo
2005 - 2008
3000 Twenty Series
Compact Utility tractor
Series map:
3120
3320
29.5hp
32.5hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
John Deere 3120 Power
Engine29.5 hp
22.0 kW
Mechanical
Four-wheel drive
Steeringpower
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the John Deere 3120 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel13.5 gal
51.1 L
Hydraulic system6.8 gal
25.7 L
Hydraulics
Typeopen center
Capacity6.8 gal
25.7 L
Valves5
Pump flow8.6 gpm
32.6 lpm
Total flow13.9 gpm
52.6 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)2530 lbs
1147 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
Mid PTOoptional
Mid PTO Type2100
Dimensions & Tires
Wheelbase68 inches
172 cm
Weight3000 lbs
1360 kg
Front tire7-14
Rear tire11.2-24
Full dimensions and tires ...
John Deere 3120 attachments
60" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
3120 Serial Numbers
2005110001
2006210001
2007310001
2008410001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging amps40
Battery CCA500
Battery volts12
References
3120 references literature
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere
3000 Series published in 2008, by John Deere
3000 Twenty Series Compact Tractors published in 2005, by John Deere
3000 Twenty Series Tractors Product Information Handbook published in 2004, by John Deere
Commercial & Consumer Equipment Purchase Guide published in 2005, by John Deere
