Kioti LB2204
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Built in Daegu, South Korea | |
| Original price was $9,000 in 1988 | |
| Kioti LB2204 Engine | |
| Daedong 1.1L 3-cyl diesel | |
 Engine details ... |
| Kioti LB2204 Transmission | |
| 8-speed gear | |
 Transmission details ... |
| Kioti LB2204 Power | |
| Engine | 22 hp 16.4 kW |
| PTO (claimed) | 19 hp 14.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Steering | manual |
| power assist optional | |
| Wet disc brakes | |
| Two-post ROPS. | |
| Photos | |
 | |
 Kioti LB2204 photos... | |
| Hydraulics | |
| Type | open center |
| Total flow | 6.7 gpm 25.4 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift | 1250 lbs 567 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Clutch | overrunning |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2430 |
| 1000@2430 | |
| Front PTO | engine |
| Front PTO Type | 2800 |
| Dimensions & Tires | |
| Wheelbase | 64.6 inches 164 cm |
| Weight | 2290 lbs 1038 kg |
| Front tire | 6-14 |
| Rear tire | 9.5-24 |
 Full dimensions and tires ... | |
| LB2204 Serial Numbers | |
| Location: | On the tractor's transmission housing ahead of the clutch pedal. |
| 1986 | 200001 |
| 1987 | 300001 |
| 1988 | 400001 |
| 1989 | 500001 |
| 1990 | 600001 |
| 1991 | 700001 |
| 1992 | 800001 |
| 1993 | 900001 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| LB2204 Four Wheel Drive Compact Tractor published in 1987, by Kitoi |
