Mahindra 3015
| | 2003 - 2008 |
| 15 Series | | Compact Utility tractor | | Mitsubishi built |
|
Series map:
2815
3015
3215
28.0hp
30.0hp
32.0hp
| Production |
| Distributor | Mahindra
|
| Manufacturer | Mitsubishi
|
| Compact Utility tractor |
| Mahindra 3015 Power |
| Engine | 30 hp
22.4 kW
|
| PTO (claimed) | 24 hp
17.9 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post foldable ROPS. |
| Photos |
| No photos of the Mahindra 3015 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Valves | 1
|
| Pump flow | 7.9 gpm
29.9 lpm
|
| Steering flow | 3.6 gpm
13.6 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift | 2205 lbs
1000 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Clutch | dry single plate
|
| Rear PTO Type | 540
|
| Engine RPM | 540@2376
|
| Mid PTO Type | 2000
|
| Engine RPM | 2000@2632
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery volts | 12
|
| Battery AH | 46
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on January 26, 2013 |
