Belarus 525
|
|
| Production | |
| Manufacturer | Belarus |
| Built in Minsk, Belarus | |
| Original price was $18,000 in 1996 | |
| Belarus 525 Engine | |
| MTZ 4.8L 4-cyl diesel | |
 Engine details ... |
| Belarus 525 Transmission | |
| 9-speed unsynchronized | |
 Transmission details ... |
| Belarus 525 Power | |
| Engine | 65 hp 48.5 kW |
| PTO (claimed) | 63 hp 47.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Mechanical disc brakes | |
| Open operator station. Cab optional with air-conditioning. |
| Photos | |
 | |
 Belarus 525 photos... | |
| Capacity | |
| Fuel | 34 gal 128.7 L |
| Hydraulic system | 4.5 gal 17.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 4.5 gal 17.0 L |
| Pressure | 2850 psi 196.5 bar |
| Valves | 2 |
| Pump flow | 10.5 gpm 39.7 lpm |
| Steering flow | 5.5 gpm 20.8 lpm |
| Steering press. | 1500 psi 103.4 bar |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 3700 lbs 1678 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1630 |
| 596@1800 | |
| Dimensions & Tires | |
| Wheelbase | 96.5 inches 245 cm |
| Weight | 6500 lbs 2948 kg |
| Front tire | 11.20-20 |
| Rear tire | 15.5-38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 50 |
| Batteries | 2 |
| Battery CCA | 900 |
| Battery volts | 6 |
| References | |
 | |
| Operators Manual 500 Series, 800 Series and 900 Series Tractors (904805) published in 1992 | |
| Belarus 525 published in 1988 |
