John Deere WA-14


John Deere WA-14 tractor photo
1968 - 1970
Four-wheel Drive (4WD) tractor
Wagner built
Series map:
WA-14
WA-17
225.0hp
280.0hp
Production
DistributorJohn Deere
ManufacturerWagner
Four-wheel Drive (4WD) tractor
Built in Portland, Oregon, USA
Total built23
Original price was $35,990 in 1969
Wagner was a tractor and logging machinery firm in Oregon. Deere contracted with Wagner to build large four-wheel-drive tractors during the period after the 8020 and before the introduction of the 7020.
John Deere WA-14 Engine
Cummins 14.0L 6-cyl diesel
Engine details ...
John Deere WA-14 Power
Engine225 hp
167.8 kW
Drawbar (claimed)178 hp
132.7 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Steeringpower
Pneumatic brakes
Open operator station. Cab optional. Heat and air-conditioning optional.
Photos
No photos of the John Deere WA-14 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel120 gal
454.2 L
Hydraulic system52 gal
196.8 L
Steering160 qts
151.4 L
Hydraulics
Typeopen center
Capacity52 gal
196.8 L
Valves2 or 3
Pump flow15 gpm
56.8 lpm
 35 gpmOptOptional
132.5 lpm
Total flow45 gpm
170.3 lpm
 65 gpmOptOptional
246.0 lpm
Steering flow30 gpm
113.6 lpm
Steering cap.160 qts
151.4 L
Dimensions & Tires
Wheelbase136 inches
345 cm
Weight26,520 lbs
12029 kg
Front tire23.1-30
Rear tire23.1-30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Batteries2
Battery volts12
Battery AH205
Battery Group8D
References
WA-14 references literature
The John Deere 20 Series New Generation Tractors by Benjamin Hain
Standard and 4-Wheel-Drive Tractors: 70 to 280 HP published in 1970, by John Deere
New 225-hp and 280-hp four-wheel-drive Tractors published in 1969, by John Deere
WA-14 and WA-17 Operator's Manual (OM-GA1002) published in 1968
