Kubota M5500
| | 1979 - 1984 |
| Utility tractor |
|
| Production |
| Manufacturer | Kubota
|
| Utility tractor |
| Built in Japan |
| Original price was $21,000 in 1984 |
| Kubota M5500 Power |
| Engine (gross) | 63 hp
47.0 kW
|
| PTO (claimed) | 55 hp
41.0 kW
|
| Drawbar (tested) | 44.06 hp
32.9 kW
|
| PTO (tested) | 53.99 hp
40.3 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | planetary
|
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post fixed ROPS. |
| Hydraulics |
| Type | open center
|
| Pressure | 2500 psi
172.4 bar
|
| Valves | 1
|
| Pump flow | 8.1 gpm
30.7 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | position and draft control
|
| Rear lift (at ends) | 3300 lbs
1496 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2016
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| Tractors and Excavators published in 1981, by Kubota |
| Tractors and Excavators published in 1982, by Kubota |
| M5500/M5500DT published in 1979, by Kubota |
| Diesel Tractor M5500 F/DT published in 1981, by Kubota |
