Kubota L245 Engine


Kubota L245 tractor photo
1976 - 1985
L Series
Compact Utility tractor
Series map:
L235
L245
L275
23.5hp
25.0hp
27.5hp
Engine Detail
Kubota DH1101
diesel
3-cylinder
liquid-cooled
Displacement68.3 ci
1.1 L
Bore/Stroke3.00x3.23 inches
76 x 82 mm
Power25 hp
18.6 kW
Air cleanerpaper element
Compression21:1
Rated RPM2800
Starterelectric
Starter volts12
Oil capacity5.2 qts
4.9 L
Coolant capacity7 qts
6.6 L
