John Deere 2750 Low-Profile


John Deere 2750 Low-Profile tractor photo
1983 - 1988
2050 Series
Orchard/Vineyard tractor
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Variants
2750utility chassis
2750 High-Clearancehigh-crop
2750 Low-Profileorchard
John Deere 2750 Low-Profile Engine
John Deere 3.9L 4-cyl diesel
Fuel tank26 gal
98.4 L
Engine details ...
John Deere 2750 Low-Profile Transmissions
8-speed partially synchronized
16-speed partial powershift
12-speed partially synchronized
Transmission details ...
John Deere 2750 Low-Profile Power
PTO (claimed)75 hp
55.9 kW
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Differential lockrear standard
Steeringhydrostatic power
Differential hydraulic wet disc brakes
Open operator station. Low-profile ROPS available.
Photos
No photos of the John Deere 2750 Low-Profile are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Pump flow23 gpm
87.1 lpm
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 540/1000 (optional)
Dimensions & Tires
2WD Wheelbase89.2 inches
226 cm
4WD Wheelbase90 inches
228 cm
Front tire27/9.5-15
Rear tire18.4-16.1 (2WD)
Full dimensions and tires ...
2750 Low-Profile Serial Numbers
Location:Right side of main tractor frame, above front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery volts12
References
2750 Low-Profile references literature
Tractors 45 to 85 HP published in 1984, by John Deere
Tractors Hi-Crop, Low-Profile, Narrow- and Wide-Tread published in 1985, by John Deere
