Kubota M4030
| | 1986 - 1989 |
| M30 Series | | Utility tractor |
|
Series map:
M4030
M5030
48.0hp
54.0hp
| Production |
| Manufacturer | Kubota
|
| Utility tractor |
| Built in Japan |
| Variants |
| M4030DT | 4WD
|
| M4030F | standard
|
| M4030L | low profile
|
| M4030SU | special utility
|
| Kubota M4030 Power |
| Engine | 48 hp
35.8 kW
|
| PTO (claimed) | 43 hp
32.1 kW
|
| Drawbar (tested) | 36.53 hp
27.2 kW
|
| PTO (tested) | 44.05 hp
32.8 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | standard
|
| Power steering |
| Differential mechanical wet disc brakes |
| Two-post ROPS. |
| Photos |
| No photos of the Kubota M4030 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 16.9 gal
64.0 L
|
| Hydraulic system | 12.7 gal (2WD)
48.1 L
|
| | 14.9 gal (4WD)
56.4 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 12.7 gal (2WD)
48.1 L
|
| | 14.9 gal (4WD)
56.4 L
|
| Pressure | 2630 psi
181.3 bar
|
| Valves | 1
|
| Total flow | 11 gpm
41.6 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Rear lift (at ends) | 3,968 lbs
1799 kg
|
| Rear lift (at 24"/610mm) | 3,307 lbs
1500 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| Engine RPM | 540@2194
|
| References |
 |
| Front Loaders published in 1988, by Kubota |
| Front Loaders B, L and M-Series published in 1994, by Kubota* |
| Product Catalog published in 1990, by Kubota |
| M30 Series - Utility/Agri/Low Profile published in 1986, by Kubota |
| M30 Series - Utility-Agri/Low Profile/Narrow/Mudder published in 1991, by Kubota |
| *Publication contains known errors. |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 6, 2023 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
Attachment details ...
