CaseIH 4230
| | 1994 - 1997 |
| 4200 Utility Series | | Utility tractor |
|
Series map:
4210
4230
4240
72.0hp
84.0hp
104.0hp
| Production |
| Manufacturer | CaseIH
|
| Utility tractor |
| Built in Doncaster, England |
| Original price was $30,000 in 1997 |
| CaseIH 4230 Power |
| Engine (gross) | 84 hp
62.6 kW
|
| Engine (net) | 79 hp
58.9 kW
|
| PTO (claimed) | 72 hp
53.7 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Final drives | planetary
|
| Differential lock | mechanical (ROPS)
|
| | electro-hydraulic (cab)
|
| Power steering |
| Hydraulic wet disc brakes |
| Two-post ROPS. Cab optional with air-conditioning. |
| Capacity |
| Fuel | 20 gal (ROPS)
75.7 L
|
| | 29.6 gal (cab)
112.0 L
|
| 2WD Hydraulic system | 9 gal
34.1 L
|
| Cab Hydraulic system | 9.7 gal
36.7 L
|
| Hydraulics |
| Type | open center
|
| 2WD Capacity | 9 gal
34.1 L
|
| Cab Capacity | 9.7 gal
36.7 L
|
| Pressure | 2500 psi
172.4 bar
|
| Valves | 0 to 3
|
| Total flow | 16.1 gpm
60.9 lpm
|
| | 18.4 gpmOptOptional
69.6 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | draft and position control
|
| Rear lift | 3,665 lbs
1662 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear PTO Type | 540 (1.375)
|
| | 540/1000 (1.375)OptOptional
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45
|
| | 65 (cab, ROPS opt.)
|
| Battery CCA | 650
|
| | 810 OptOptional
|
| Battery volts | 12
|
| References |
 |
| New 3200 and 4200 Series Tractors published in 1994, by Case IH |
| 3200/4200 Series Tractors published in 1994, by Case IH |
