CaseIH 2594
| | 1984 - 1988 |
| Row-Crop tractor |
|
Series map:
2394
2594
197.0hp
217.0hp
Note: the CaseIH model 2594 is the same as the J.I. Case 2594. The following data is from the 2594 listing. |
| Production |
| Manufacturer | CaseIH
|
| Row-Crop tractor |
| Built in Racine, Wisconsin, USA |
| CaseIH 2594 Power |
| Engine | 217 hp
161.8 kW
|
| Drawbar (claimed) | 161 hp
120.1 kW
|
| PTO (claimed) | 180 hp
134.2 kW
|
| Drawbar (tested) | 159.64 hp
119.0 kW
|
| PTO (tested) | 182.07 hp
135.8 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Power steering |
| Wet disc brakes |
| Silent Guardian cab with air-conditioning. |
| Capacity |
| Fuel | 85 gal
321.7 L
|
| | 25 gal (optional auxiliary tank)
94.6 L
|
| Hydraulic system | 32 gal
121.1 L
|
| Hydraulics |
| Type | closed center
|
| Capacity | 32 gal
121.1 L
|
| Pressure | 2250 psi
155.1 bar
|
| Valves | 2 to 4
|
| Pump flow | 27 gpm
102.2 lpm
|
| Steering flow | 8 gpm
30.3 lpm
|
| Steering press. | 2000 psi
137.9 bar
|
| Tractor hitch |
| Rear Type | III
|
| Rear lift (at 24"/610mm) | 7,750 lbs
3515 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic
|
| Rear PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 72
|
| | 105 OptOptional
|
| Battery volts | 12
|
| References |
 |
| 2 Wheel Drive and Mechanical Front Drive Tractors published in 1987, by CaseIH |
| 1985 Farm Equipment Buyer's Guide published by CaseIH |
