Steiger Panther KP-1400
|
|
| Production | |
| Manufacturer | Steiger |
| Four-wheel Drive (4WD) tractor | |
| Built in Fargo, North Dakota, USA | |
| Original price was $145,000 in 1985 | |
| Variants | |
| CP-1325 | Caterpillar 325HP |
| KP-1325 | Cummins 325HP |
| CP-1360 | Caterpillar 360HP |
| KP-1360 | Cummins 360HP |
| CP-1400 | Caterpillar 400HP |
| KP-1400 | Cummins 400HP |
| Steiger Panther KP-1400 Engine | |
| Cummins 14.0L 6-cyl diesel | |
| Fuel tank | 230 gal 870.6 L |
 Engine details ... | |
| Steiger Panther KP-1400 Transmission | |
| 12-speed full power shift | |
 Transmission details ... |
| Steiger Panther KP-1400 Power | |
| Engine | 400 hp 298.3 kW |
| Drawbar (claimed) | 332 hp 247.6 kW |
| Drawbar (tested) | 327.93 hp 244.5 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | outboard planetary |
| Articulated power steering | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Steiger Panther KP-1400 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center |
| Valves | 3 |
| Dimensions & Tires | |
| Wheelbase | 141.5 inches 359 cm |
| Weight | 36,550 lbs 16579 kg |
| Front tire | 24.5-32 |
| Rear tire | 24.5-32 |
 Full dimensions and tires ... | |
| Panther KP-1400 Serial Numbers | |
| 1982 | P10-00501 |
| 1983 | P10-02501 |
| 1984 | P10-03001 |
| 1985 | P10-05001 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| The Steiger Line published in 1983 |
