Steiger Panther IV CS-325


Steiger Panther IV CS-325 tractor photo
1984 - 1985
IV Series
Four-wheel Drive (4WD) tractor
Production
ManufacturerSteiger
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Variants
CM325Caterpillar gear shift
CS325Caterpillar power shift
KM325Cummins gear shift
KS325Cummins power shift
SM325Komatsu gear shift
Steiger Panther IV CS-325 Engine
Caterpillar 14.6L 6-cyl diesel
Fuel tank225 gal
851.6 L
Engine details ...
Steiger Panther IV CS-325 Power
Engine325 hp
242.4 kW
Drawbar (claimed)272.5 hp
203.2 kW
Mechanical
Four-wheel drive
Final drivesoutboard planetary
Articulated power steering
Hydraulic disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Steiger Panther IV CS-325 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2250 psi
155.1 bar
Valves3 to 5
Pump flow31.3 gpm
118.5 lpm
Tractor hitch
Rear TypeIII OptOptional
Dimensions & Tires
Wheelbase132.5 inches
336 cm
Weight27224 lbs
12348 kg
Front tire20.8-38
Rear tire20.8-38
Full dimensions and tires ...
Panther IV CS-325 Serial Numbers
1984150-03001
1985150-05001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Batteries4
Battery volts12
References
Panther IV CS-325 references literature
Cougar IV/Panter IV Steigermatic published in 1984
