Steiger Panther IV CM-325


Steiger Panther IV CM-325 tractor photo
1983 - 1985
IV Series
Four-wheel Drive (4WD) tractor
Production
ManufacturerSteiger
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Variants
CM325Caterpillar gear shift
CS325Caterpillar power shift
KM325Cummins gear shift
KS325Cummins power shift
SM325Komatsu gear shift
Steiger Panther IV CM-325 Engine
Caterpillar 14.6L 6-cyl diesel
Fuel tank267 gal
1010.6 L
Engine details ...
Steiger Panther IV CM-325 Transmission
20-speed Constant mesh 10-speed transmission with 2-speed transfer case.
Transmission details ...
Steiger Panther IV CM-325 Power
Engine325 hp
242.4 kW
Drawbar (claimed)273 hp
203.6 kW
Mechanical
Four-wheel drive
Articulated power steering
Hydraulic disc brakes
Steiger Safari Cab standard with air-conditioning.
Photos
No photos of the Steiger Panther IV CM-325 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center load sensing
Pressure2250 psi
155.1 bar
Valves3 to 5
Pump flow31 gpm
117.3 lpm
Tractor hitch
Rear TypeIII OptOptional
Dimensions & Tires
Wheelbase129 inches
327 cm
Weight26903 lbs
12203 kg
Front tire23.1x34
Rear tire23.1x34
Full dimensions and tires ...
Panther IV CM-325 Serial Number Location
Steiger Panther IV CM-325 serial number location
Serial number plate on the left-side fender.
Panther IV CM-325 Serial Numbers
1983123-03001
1984123-03201
1985123-05001

FAQ: How to read a serial number table.
Electrical
Charging systemalternator
Charging amps90
Batteries3
Battery volts12
References
Panther IV CM-325 references literature
Panther IV published in 1983, by Steiger
The Steiger Line published in 1983
