Steiger Cougar IV KM-280
|
|
| Production | |
| Manufacturer | Steiger |
| Four-wheel Drive (4WD) tractor | |
| Built in Fargo, North Dakota, USA | |
| Steiger Cougar IV KM-280 Engine | |
| Cummins 14.0L 6-cyl diesel | |
| Fuel tank | 267 gal 1010.6 L |
 Engine details ... | |
| Steiger Cougar IV KM-280 Power | |
| Engine | 280 hp 208.8 kW |
| Drawbar (claimed) | 255 hp 190.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | outboard planetary |
| Articulated power steering | |
| Hydraulic disc brakes | |
| Steiger Safari Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Steiger Cougar IV KM-280 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2250 psi 155.1 bar |
| Valves | 3 to 5 |
| Pump flow | 28.6 gpm 108.3 lpm |
| Tractor hitch | |
| Rear Type | III OptOptional |
| Dimensions & Tires | |
| Wheelbase | 129 inches 327 cm |
| Weight | 25011 lbs 11344 kg |
| Front tire | 18.4x38 |
| Rear tire | 18.4x38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 90 |
| Batteries | 3 |
| Battery volts | 12 |
| References | |
 | |
| Cougar IV published in 1983, by Steiger | |
| The Steiger Line published in 1983 |
