Steiger Cougar IV CM-280


Steiger Cougar IV CM-280 tractor photo
1983 - 1985
IV Series
Four-wheel Drive (4WD) tractor
Production
ManufacturerSteiger
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Steiger Cougar IV CM-280 Engine
Caterpillar 14.6L 6-cyl diesel
Fuel tank267 gal
1010.6 L
Engine details ...
Steiger Cougar IV CM-280 Power
Engine280 hp
208.8 kW
Drawbar (claimed)252 hp
187.9 kW
Mechanical
Four-wheel drive
Final drivesoutboard planetary
Articulated power steering
Hydraulic disc brakes
Steiger Safari Cab standard with air-conditioning.
Photos
No photos of the Steiger Cougar IV CM-280 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2250 psi
155.1 bar
Valves3 to 5
Pump flow31 gpm
117.3 lpm
Tractor hitch
Rear TypeIII Opt
Dimensions & Tires
Wheelbase129 inches
327 cm
Weight25011 lbs
11344 kg
Front tire18.4x38
Rear tire18.4x38
Full dimensions and tires ...
Electrical
Charging systemalternator
Charging amps90
Batteries3
Battery volts12
References
Cougar IV CM-280 references literature
Cougar IV published in 1983, by Steiger
The Steiger Line published in 1983
