CaseIH Vestrum 110
|
|
| Production | |
| Manufacturer | CaseIH (a part of CNH) |
| Utility tractor | |
| Variants | |
| T5.120 | similar New Holland model |
| CaseIH Vestrum 110 Engine | |
| FPT 4.5L 4-cyl diesel | |
| Fuel tank | 47.5 gal 179.8 L |
| Exhaust fluid (DEF) | 5 gal 18.9 L |
 Engine details ... | |
| CaseIH Vestrum 110 Transmissions | |
| continuously-variable transmission | |
| 24-speed 8-speed power shift | |
 Transmission details ... |
| CaseIH Vestrum 110 Power | |
| Engine (gross) | 108.5 hp 80.9 kW |
| Engine (max) | 118.4 hp 88.3 kW |
| PTO (claimed) | 88 hp 65.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | electro-hydraulic rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Vestrum 110 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load-sensing |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 4 OptOptional |
| Mid valves | 3 OptOptional |
| Pump flow | 29.1 gpm 110.1 lpm |
| Tractor hitch | |
| Rear Type | II |
| IIIN OptOptional | |
| Control | electronic lower-link draft sensing |
| Rear lift (at 24"/610mm) | 9259 lbs 4199 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1969 |
| 540E@1546 | |
| 1000@1893 | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 98 inches 248 cm |
| Weight | 12900 lbs 5851 kg |
| Front tire | 380/85R24 |
| Rear tire | 460/85R34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 200 |
| Battery volts | 12 |
| References | |
 | |
| Vestrum published in 2023, by CaseIH |
