Minneapolis-Moline G850


Minneapolis-Moline G850 tractor photo
1971 - 1972
Row-Crop tractor
Series map:
G750
G850
77.8hp*
95.6hp*
*Estimated engine power for comparison only.

Note: the Minneapolis-Moline model G850 is the same as the Oliver 1755. The following data is from the 1755 listing.
Production
ManufacturerMinneapolis-Moline (a part of White)
Row-Crop tractor
Original price was $11,500 in 1975
Minneapolis-Moline G850 Engines
Waukesha-Oliver 5.1L 6-cyl diesel
Waukesha-Oliver 4.6L 6-cyl gasoline
Engine details ...
Minneapolis-Moline G850 Transmissions
6-speed gear
18-speed partial power shift
Transmission details ...
Minneapolis-Moline G850 Power
PTO (claimed)86 hp
64.1 kW
Drawbar (tested)73.87 hp
55.1 kW
PTO (tested)86.93 hp
64.8 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Differential hydraulic dry disc brakes
Open operator station. Optional two-post ROPS and cab.
Capacity
Fuel35 gal
132.5 L
Hydraulic system6.75 gal
25.5 L
Hydraulics
Typeclosed center
Capacity6.75 gal
25.5 L
Pump flow20 gpm
75.7 lpm
Tractor hitch
Rear TypeI/II
 II/III OptOptional
Rear lift4,000 lbs
1814 kg
 6,000 lbs (Cat 3)
2721 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 1000
Dimensions & Tires
2WD Wheelbase103 inches
261 cm
4WD Wheelbase86.25 inches
219 cm
Weight9,600 lbs
4354 kg
Front tire7.50-15
Rear tire18.4-34
Full dimensions and tires ...
G850 Serial Numbers
1970221-603
1971226-445
1972231-415
1973238-136
1974245-667
1975257-515
Final260-346

FAQ: How to read a serial number table.
References
G850 references literature
Models G850/G940 published in 1971, by Minneapolis-Moline
