Minneapolis-Moline G750


Minneapolis-Moline G750 tractor photo
1969 - 1975
Row-Crop tractor
Series map:
G750
G850
77.8hp*
95.6hp*
*Estimated engine power for comparison only.

Note: the Minneapolis-Moline model G750 is the same as the Oliver 1655. The following data is from the 1655 listing.
Production
ManufacturerMinneapolis-Moline (a part of White)
Row-Crop tractor
Original price was $10,000 in 1975
Minneapolis-Moline G750 Engines
Waukesha-Oliver 4.6L 6-cyl diesel
Waukesha-Oliver 4.3L 6-cyl gasoline
Engine details ...
Minneapolis-Moline G750 Transmissions
18-speed partial power shift
6-speed helical gear
Transmission details ...
Minneapolis-Moline G750 Power
PTO (claimed)70 hp
52.2 kW
Drawbar (tested)60.07 hp
44.8 kW
PTO (tested)70.57 hp
52.6 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Disc brakes
Open operator station. Cab optional with available heater.
Capacity
Fuel27.5 gal
104.1 L
Hydraulic system14 gal
53.0 L
Hydraulics
Typeopen center
Capacity14 gal
53.0 L
Valves2 to 4
Tractor hitch
Rear TypeII/I
Controllower-link draft control
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 1000
 540/1000
Dimensions & Tires
2WD Wheelbase99.25 inches
252 cm
4WD Wheelbase82.125 inches
208 cm
Weight7500 to 8000 pounds
Front tire7.50-16
Rear tire18.4-34
Full dimensions and tires ...
G750 Serial Number Location
Minneapolis-Moline G750 serial number location
Serial number plate below instrument panel.
G750 Serial Numbers
1969218-025
1970222-600
1971222-761
1972231-772
1973236-586
1974244-735
1975257-700
Final263-340

FAQ: How to read a serial number table.
References
G750 references literature
Model G750 published in 1971, by Minneapolis-Moline
