John Deere 7230 Premium



John Deere 7230 Premium tractor photo
2007 - 2011
7030 Small-Frame Series
Row-Crop tractor
Series map:
7130 Premium
7230 Premium
7330 Premium
121.0hp
131.0hp
155.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Original price$107,075 (2011)
Variants
7230base tractor
7230 Premiumdeluxe tractor
John Deere 7230 Premium Engine
John Deere 6.8L 6-cyl diesel
Engine details ...
John Deere 7230 Premium Transmissions
16-speed partial power shift
24-speed partial power shift
infinitely variable transmission
28-speed partial power shift
Transmission details ...
John Deere 7230 Premium Power
Engine (gross)131 hp
97.7 kW
PTO (claimed)110 hp
82.0 kW
Drawbar (tested)102.19 hp
76.2 kW
PTO (tested)126.93 hp
94.7 kW
Performance test details ...
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Steeringhydrostatic power
Hydraulic wet disc brakes
ComfordGard cab standard. Optional Deluxe, Premium, and Premium Plus option packages add radio, automatic temperature control and hydraulic suspension.
Photos
No photos of the John Deere 7230 Premium are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel54.7 gal
207.0 L
Hydraulic system13.7 gal
51.9 L
 15.9 gal (IVT)
60.2 L
Hydraulics
Typeclosed center pressure and flow compensated (PFC)
Capacity13.7 gal
51.9 L
 15.9 gal (IVT)
60.2 L
Pressure2900 psi
200.0 bar
Rear valves2 to 4
Pump flow29 gpm
109.8 lpm
Tractor hitch
Rear Type2
 2N/2 (optional)
Controlelectronic lower link
Rear lift (at 24"/610mm)5,110 lbs
2317 kg
 8,262 lbs (optional)
3747 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
 540/540E/1000 (optional)
Engine RPM540@2143
 540E@1684
 1000@2208
Dimensions & Tires
Wheelbase112.8 inches (2WD)
286 cm
 104.3 inches (4WD)
264 cm
Weight10800 to 12005 pounds
Front tire11.00-16
Rear tire18.4R38 (2WD)
Full dimensions and tires ...
7230 Premium Serial Numbers
Location:Right side of main frame above front axle
Electrical
Groundnegative
Charging systemalternator
Charging volts14
Battery volts12
References
7230 Premium references literature
6030 and 7030 Series Tractors published in 2007, by John Deere
