| | 1936 - 1948 |
| ZT Series | | Row-Crop tractor |
|
Series map:
ZTU
29.4hp*
*Estimated engine power for comparison only.
| Engine Detail |
| Minneapolis-Moline RE |
| gasoline |
| 4-cylinder |
| liquid-cooled |
| Displacement | 185.8 ci
3.0 L
|
| Bore/Stroke | 3.625x4.50 inches
92 x 114 mm
|
| Air cleaner | oil bath
|
| Compression | 5.75:1
|
| Rated RPM | 1500
|
| Firing order | 1-3-4-2
|
| Coolant capacity | 14 qts
13.2 L
|
| Engine Oil |
|
| Oil capacity | 7 qts
6.6 L
|
