Challenger 65B
|
|
| Production | |
| Manufacturer | Challenger (a part of Caterpillar) |
| Agricultural Crawler tractor | |
| Challenger 65B Engine | |
| Caterpillar 10.5L 6-cyl diesel | |
| Fuel tank | 220 gal 832.7 L |
 Engine details ... | |
| Challenger 65B Transmission | |
| 10-speed full power shift | |
 Transmission details ... |
| Challenger 65B Power | |
| Engine | 285 hp 212.5 kW |
| Drawbar (tested) | 220.32 hp 164.3 kW |
| PTO (tested) | 257.20 hp 191.8 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | crawler |
| Steering | hydrostatic differential steering |
| Hydraulic caliper disc brakes | |
| Cab standard | |
| Photos | |
| No photos of the Challenger 65B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed |
| Valves | 4 |
| Pump flow | 26 gpm 98.4 lpm |
| Tractor hitch | |
| Rear Type | III/IV |
| Rear lift | 11,370 lbs 5157 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 1000 |
| Dimensions & Tracks | |
| Wheelbase | 106 inches 269 cm |
| Weight | 34,030 lbs 15436 kg |
| 24.5-inch tracks | |
 Full dimensions and tracks ... | |
| References | |
 | |
| Challenger 65B published in 1991, by Caterpillar |
