Massey Ferguson 390T Engine
|
|
| Engine Detail | |
| Perkins AT4.236 | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement | 236 ci 3.9 L |
| Bore/Stroke | 3.875x5.00 inches 98 x 127 mm |
| Power | 92 hp 68.6 kW |
| Fuel system | direct injection |
| Air cleaner | dual dry element |
| Compression | 15.5:1 |
| Rated RPM | 2200 |
| Idle RPM | 750-2310 |
| Torque | 258 lb-ft 349.8 Nm |
| Torque RPM | 1400 |
| Firing order | 1-3-4-2 |
| Starter | electric |
| Starter volts | 12 |
| Oil capacity | 8.1 qts 7.7 L |
| Coolant capacity | 16.4 qts 15.5 L |
