Massey Ferguson 375
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Utility tractor | |
| Built in Coventry, England | |
| Original price was $28,100 in 1997 | |
| Massey Ferguson 375 Engine | |
| Perkins 3.9L 4-cyl diesel | |
 Engine details ... |
| Massey Ferguson 375 Transmissions | |
| 12-speed synchromesh | |
| 12-speed two-speed power shift | |
| 8-speed | |
| 12-speed synchronized shuttle | |
 Transmission details ... |
| Massey Ferguson 375 Power | |
| Engine | 70 hp 52.2 kW |
| PTO (claimed) | 63 hp 47.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Differential wet disc brakes | |
| Two-post fixed ROPS. Cab optional with air-conditioning. |
| Photos | |
| No photos of the Massey Ferguson 375 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 28.5 gal 107.9 L |
| Hydraulic system | 11.5 gal 43.5 L |
| Hydraulics | |
| Type | open center |
| Capacity | 11.5 gal 43.5 L |
| Pressure | 3000 psi 206.8 bar |
| Valves | 2 |
| Pump flow | 9.5 gpm (aux pump) 36.0 lpm |
| 4.4 gpm (hitch) 16.7 lpm | |
| Total flow | 13.9 gpm 52.6 lpm |
| 16.8 gpmOptOptional 63.6 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Rear lift | 4250 lbs*Capacity through full lift range 1927 kg |
| Rear lift (at ends) | 4729 lbs (II/I interchangeable)*Capacity with links horizontal 2145 kg |
| 5575 lbs (II/I interchangeable with assist ram)*Capacity with links horizontal 2528 kg | |
| 5701 lbs (II fixed)*Capacity with links horizontal 2585 kg | |
| 6744 lbs (II fixed with assist ram)*Capacity with links horizontal 3059 kg | |
| 5410 lbs (II wrist-action)*Capacity with links horizontal 2453 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| live OptOptional | |
| Rear PTO Type | 540/1000 (1.375) |
| 540 (1.375) | |
| Dimensions & Tires | |
| 2WD Wheelbase | 84.1 inches 213 cm |
| 4WD Wheelbase | 92.5 inches 234 cm |
| Weight | 6240 to 7517 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 18.4/15-30 |
 Full dimensions and tires ... | |
| Massey Ferguson 375 attachments | |
| front-end loader | |
 Attachment details ... |
| 375 Serial Number Location | |
 | |
| Serial number plate on the right side of the tractor, near the brake pedals. |
| 375 Serial Numbers | |
| 1986 | U01001 |
| 1987 | V01001 |
| 1988 | N01001 |
| 1989 | P01001 |
| 1990 | R01001 |
| 1991 | S01001 |
| 1992 | A01001 |
| 1993 | B01001 |
| 1994 | C01001 |
| 1995 | D01001 |
| 1996 | E01001 |
| 1997 | F01001 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 |
| Battery CCA | 420 (2x) |
| 540 (1x) | |
| Battery volts | 12 |
| References | |
 | |
| Loaders - Compact and Agricultural published in 1989, by Massey Ferguson | |
| 300 published in 1988, by Massey Ferguson | |
| 300 published in 1989, by Massey Ferguson | |
| M-F 300 Series published in 1990, by Massey Ferguson | |
| 300 Series HILINE Tractor Cab published in 1992, by Massey Ferguson | |
| 300 Series published in 1992, by Massey Ferguson | |
| MF 300 Series published in 1994, by Massey Ferguson | |
| 300 Series Tractors Data Book published in 1992, by Massey Ferguson | |
| M-F 300 Series Tractor Workshop Manual (1449 244M1) published in 1991 |
