Massey Ferguson 375


Massey Ferguson 375 tractor photo
1987 - 1997
Model year
300 Series
Utility tractor
Series map:
360
375
383
57.0hp
70.0hp
76.0hp
Production
ManufacturerMassey Ferguson
Utility tractor
Built in Coventry, England
Original price was $28,100 in 1997
Massey Ferguson 375 Transmissions
12-speed synchromesh
12-speed two-speed power shift
8-speed
12-speed synchronized shuttle
Transmission details ...
Massey Ferguson 375 Power
Engine70 hp
52.2 kW
PTO (claimed)63 hp
47.0 kW
Mechanical
Two- or four-wheel drive
Power steering
Differential wet disc brakes
Two-post fixed ROPS. Cab optional with air-conditioning.
Photos
No photos of the Massey Ferguson 375 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel28.5 gal
107.9 L
Hydraulic system11.5 gal
43.5 L
Hydraulics
Typeopen center
Capacity11.5 gal
43.5 L
Pressure3000 psi
206.8 bar
Valves2
Pump flow9.5 gpm (aux pump)
36.0 lpm
 4.4 gpm (hitch)
16.7 lpm
Total flow13.9 gpm
52.6 lpm
 16.8 gpmOptOptional
63.6 lpm
Tractor hitch
Rear TypeII
Rear lift4250 lbs*Capacity through full lift range
1927 kg
Rear lift (at ends)4729 lbs (II/I interchangeable)*Capacity with links horizontal
2145 kg
 5575 lbs (II/I interchangeable with assist ram)*Capacity with links horizontal
2528 kg
 5701 lbs (II fixed)*Capacity with links horizontal
2585 kg
 6744 lbs (II fixed with assist ram)*Capacity with links horizontal
3059 kg
 5410 lbs (II wrist-action)*Capacity with links horizontal
2453 kg
Power Take-off (PTO)
Rear PTOindependent
 live OptOptional
Rear PTO Type540/1000 (1.375)
 540 (1.375)
Dimensions & Tires
2WD Wheelbase84.1 inches
213 cm
4WD Wheelbase92.5 inches
234 cm
Weight6240 to 7517 pounds
Front tire7.50-16
2WD Rear tire18.4/15-30
Full dimensions and tires ...
375 Serial Number Location
Massey Ferguson 375 serial number location
Serial number plate on the right side of the tractor, near the brake pedals.
375 Serial Numbers
1986U01001
1987V01001
1988N01001
1989P01001
1990R01001
1991S01001
1992A01001
1993B01001
1994C01001
1995D01001
1996E01001
1997F01001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps45
Battery CCA420 (2x)
 540 (1x)
Battery volts12
References
375 references literature
Loaders - Compact and Agricultural published in 1989, by Massey Ferguson
300 published in 1988, by Massey Ferguson
300 published in 1989, by Massey Ferguson
M-F 300 Series published in 1990, by Massey Ferguson
300 Series HILINE Tractor Cab published in 1992, by Massey Ferguson
300 Series published in 1992, by Massey Ferguson
MF 300 Series published in 1994, by Massey Ferguson
300 Series Tractors Data Book published in 1992, by Massey Ferguson
M-F 300 Series Tractor Workshop Manual (1449 244M1) published in 1991
