Engine Detail | |
Perkins A4.236 | |
diesel | |
4-cylinder | |
liquid-cooled | |
Displacement | 236 ci 3.9 L |
Bore/Stroke | 3.875x5.00 inches 98 x 127 mm |
Power | 70 hp 52.2 kW |
Fuel system | direct injection |
Air cleaner | dual dry element |
Compression | 16:1 |
Rated RPM | 2200 |
Idle RPM | 750-2310 |
Torque | 198 lb-ft 268.5 Nm |
Torque RPM | 1400 |
Firing order | 1-3-4-2 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 7.9 qts 7.5 L |
Coolant capacity | 16 qts 15.1 L |
