Engine Detail | |
Perkins A4.236 | |
diesel | |
4-cylinder | |
liquid-cooled | |
Displacement | 236 ci 3.9 L |
Bore/Stroke | 3.875x5.00 inches 98 x 127 mm |
Power | 61 hp 45.5 kW |
Fuel system | direct injection |
Air cleaner | dual dry element |
Compression | 16:1 |
Rated RPM | 2200 |
Idle RPM | 750-2310 |
Torque | 179 lb-ft 242.7 Nm |
Torque RPM | 1400 |
Firing order | 1-3-4-2 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 7.2 qts 6.8 L |
Coolant capacity | 15.2 qts 14.4 L |
