Tractor Tests | |
NTTL 657: LP gas 6-speed 2WD | |
NTTL 659: gasoline 6-speed 2WD | |
NTTL 745: 203 diesel 6-speed 2WD | |
NTTL 808: 203 diesel 12-speed 2WD |
Nebraska Tractor Test 657 | |||
|
Nebraska Tractor Test 657 | |
LP gas 6-speed 2WD June 16 - 27, 1958 Link: Nebraska Tractor Test 657 file | |
Belt power (max) | 42.6 hp 31.8 kW |
Belt fuel use (max) | 5.2 gal/hour 19.7 l/hour |
PTO performance | |
Power at rated engine speed | 38.15 hp 28.4 kW |
Fuel use | 5.0 gal/hour 18.9 l/hour |
Drawbar performance | |
Max power | 31.24 hp 23.3 kW |
Fuel use | 4.7 gal/hour 17.8 l/hour |
Gear 4 used for power test. | |
Max pull | 6,832 lbs 3098 kg |
Gear 2 used for pull test. |
Nebraska Tractor Test 659 | |||
|
Nebraska Tractor Test 659 | |
Gasoline 6-speed 2WD June 16 - 27, 1958 Link: Nebraska Tractor Test 659 file | |
Belt power (max) | 43.98 hp 32.8 kW |
Belt fuel use (max) | 3.9 gal/hour 14.8 l/hour |
PTO performance | |
Power at rated engine speed | 40.76 hp 30.4 kW |
Fuel use | 3.9 gal/hour 14.8 l/hour |
Drawbar performance | |
Max power | 32.63 hp 24.3 kW |
Fuel use | 3.8 gal/hour 14.4 l/hour |
Gear 4 used for power test. |
Nebraska Tractor Test 745 | |||
|
Nebraska Tractor Test 745 | |
203 diesel 6-speed 2WD May 16 - 24, 1960 Link: Nebraska Tractor Test 745 file | |
PTO performance | |
Power at rated engine speed | 48.59 hp 36.2 kW |
Fuel use | 3.1 gal/hour 11.7 l/hour |
Power at rated PTO speed | 39.67 hp 29.6 kW |
Fuel use | 2.4 gal/hour 9.1 l/hour |
Drawbar performance | |
Max power | 42.13 hp 31.4 kW |
Fuel use | 3.1 gal/hour 11.7 l/hour |
Gear 4 used for power test. |
Nebraska Tractor Test 808 | |||
|
Nebraska Tractor Test 808 | |
203 diesel 12-speed 2WD October 24 - November 3, 1961 Link: Nebraska Tractor Test 808 file | |
PTO performance | |
Power at rated engine speed | 50.98 hp 38.0 kW |
Fuel use | 3.1 gal/hour 11.7 l/hour |
Power at rated PTO speed | 42.67 hp 31.8 kW |
Fuel use | 2.5 gal/hour 9.5 l/hour |
Drawbar performance | |
Max power | 43.95 hp 32.8 kW |
Fuel use | 3.2 gal/hour 12.1 l/hour |
Gear 7 used for power test. | |
Max pull | 7029 lbs 3188 kg |
Gear 3 used for pull test. |
