Tractor Tests | |
NTTL 768: diesel 6-speed 2WD | |
NTTL 824: Series B diesel 12-speed 2WD | |
NTTL 847: Series B diesel 12-speed 4WD |
Nebraska Tractor Test 768 | |||
|
Nebraska Tractor Test 768 | |
Diesel 6-speed 2WD October 3 - 8, 1960 Link: Nebraska Tractor Test 768 file | |
PTO performance | |
Max power | 89.35 hp 66.6 kW |
Fuel use | 6.2 gal/hour 23.5 l/hour |
Drawbar performance | |
Max power | 82.85 hp 61.8 kW |
Fuel use | 6.4 gal/hour 24.2 l/hour |
Gear 4 used for power test. | |
Max pull | 12,475 lbs 5658 kg |
Gear 1 used for pull test. |
Nebraska Tractor Test 824 | |||
|
Nebraska Tractor Test 824 | |
Series B diesel 12-speed 2WD September 17 - 23, 1962 Link: Nebraska Tractor Test 824 file | |
PTO performance | |
Power at rated engine speed | 98.54 hp 73.5 kW |
Fuel use | 6.6 gal/hour 25.0 l/hour |
Drawbar performance | |
Max power | 84.44 hp 63.0 kW |
Fuel use | 6.5 gal/hour 24.6 l/hour |
Gear 4-Direct used for power test. | |
Max pull | 13,471 lbs 6110 kg |
Gear 2-Hydra-Power used for pull test. |
Nebraska Tractor Test 847 | |||
|
Nebraska Tractor Test 847 | |
Series B diesel 12-speed 4WD September 13 - 20, 1963 Link: Nebraska Tractor Test 847 file | |
PTO performance | |
Power at rated engine speed | 100.62 hp 75.0 kW |
Fuel use | 7.5 gal/hour 28.4 l/hour |
Drawbar performance | |
Max power | 88.27 hp 65.8 kW |
Fuel use | 7.2 gal/hour 27.3 l/hour |
Gear 4-Direct used for power test. | |
Max pull | 16,991 lbs 7707 kg |
Gear 1-Direct used for pull test. |
