Oliver 1855


Oliver 1855 tractor photo
1969 - 1975
55 Series
Row-Crop tractor
Series map:
1755
1855
1955
95.6hp*
102.2hp*
120.0hp*
*Estimated engine power for comparison only.
Production
ManufacturerOliver (a part of White)
Row-Crop tractor
Original price was $13,000 in 1975
Oliver 1855 Engines
Oliver-Waukesha 5.1L 6-cyl diesel
Oliver-Waukesha 5.1L 6-cyl gasoline
Fuel tank35 gal
132.5 L
Engine details ...
Oliver 1855 Transmissions
6-speed gear
18-speed partial power shift
Transmission details ...
Oliver 1855 Power
PTO (claimed)92 hp (gas)
68.6 kW
 98 hp (diesel)
73.1 kW
Drawbar (tested)82.65 hp
61.6 kW
PTO (tested)98.60 hp
73.5 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Differential hydraulic disc brakes
Open operator station. Optional two-post ROPS and cab.
Hydraulics
Typeclosed center
Pump flow20 gpm
75.7 lpm
Tractor hitch
Rear TypeI/II
 II/III (optional)
Rear lift4,000 lbs
1814 kg
 6,000 lbs (Cat 3)
2721 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 540/1000
 1000
Engine RPM984@2400
Dimensions & Tires
2WD Wheelbase103 inches
261 cm
4WD Wheelbase86.25 inches
219 cm
Weight11,150 lbs
5057 kg
Front tire11L-15
Rear tire23.1-34
Full dimensions and tires ...
1855 Serial Numbers
1969220-640
1970221-099
1971225-508
1972231-366
1973236-585
1974247-436
1975255-727
Final255-785

FAQ: How to read a serial number table.
References
1855 references literature
1755/1855/1955 published in 1970, by Oliver
1755/1855/1955 published in 1970, by White
A Modern Line-Up in Power published in 1969, by Oliver
