Oliver 1755


Oliver 1755 tractor photo
1970 - 1975
55 Series
Row-Crop tractor
Series map:
1755
1855
95.6hp*
102.2hp*
*Estimated engine power for comparison only.
Production
ManufacturerOliver (a part of White)
Row-Crop tractor
Original price was $11,500 in 1975
Variants
G850similar Minneapolis-Moline model
Oliver 1755 Engines
Waukesha-Oliver 5.1L 6-cyl diesel
Waukesha-Oliver 4.6L 6-cyl gasoline
Engine details ...
Oliver 1755 Transmissions
6-speed gear
18-speed partial power shift
Transmission details ...
Oliver 1755 Power
PTO (claimed)86 hp
64.1 kW
Drawbar (tested)73.87 hp
55.1 kW
PTO (tested)86.93 hp
64.8 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Differential hydraulic dry disc brakes
Open operator station. Optional two-post ROPS and cab.
Capacity
Fuel35 gal
132.5 L
Hydraulic system6.75 gal
25.5 L
Hydraulics
Typeclosed center
Capacity6.75 gal
25.5 L
Pump flow20 gpm
75.7 lpm
Tractor hitch
Rear TypeI/II
 II/III OptOptional
Rear lift4,000 lbs
1814 kg
 6,000 lbs (Cat 3)
2721 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 1000
Dimensions & Tires
2WD Wheelbase103 inches
261 cm
4WD Wheelbase86.25 inches
219 cm
Weight9,600 lbs
4354 kg
Front tire7.50-15
Rear tire18.4-34
Full dimensions and tires ...
1755 Serial Numbers
1970221-603
1971226-445
1972231-415
1973238-136
1974245-667
1975257-515
Final260-346

FAQ: How to read a serial number table.
References
1755 references literature
1755/1855/1955 published in 1970, by Oliver
1755/1855/1955 published in 1970, by White
A Modern Line-Up in Power published in 1969, by Oliver
1975 Farm Equipment Line published by White
