New Holland 5610 Tests
|
|
Note: the New Holland model 5610 is the same as the Ford 5610. The following data is from the 5610 listing. |
| Tractor Tests | |
| NTTL 1428: diesel 16x4 4WD | |
| NTTL 1429: diesel 16x8 2WD |
| Nebraska Tractor Test 1428 | |||
| |||
| Nebraska Tractor Test 1428 | |
| Diesel 16x4 4WD March 25 - April 19, 1982 Link: Nebraska Tractor Test 1428 file | |
| PTO performance | |
| Power at rated engine speed | 62.54 hp 46.6 kW |
| Fuel use | 4.2 gal/hour 15.9 l/hour |
| Power at rated PTO speed | 60.58 hp 45.2 kW |
| Fuel use | 3.9 gal/hour 14.8 l/hour |
| Drawbar performance | |
| Max power | 53.43 hp 39.8 kW |
| Fuel use | 4.2 gal/hour 15.9 l/hour |
| Gear 6L used for power test. | |
| Max pull | 7,408 lbs 3360 kg |
| Gear 3L used for pull test. | |
| Nebraska Tractor Test 1429 | |||
| |||
| Nebraska Tractor Test 1429 | |
| Diesel 16x8 2WD April 5 - May 6, 1982 Link: Nebraska Tractor Test 1429 file | |
| PTO performance | |
| Power at rated engine speed | 62.57 hp 46.7 kW |
| Fuel use | 4.2 gal/hour 15.9 l/hour |
| Power at rated PTO speed | 59.99 hp 44.7 kW |
| Fuel use | 3.9 gal/hour 14.8 l/hour |
| Drawbar performance | |
| Max power | 52.98 hp 39.5 kW |
| Fuel use | 4.1 gal/hour 15.5 l/hour |
| Gear 6L used for power test. | |
| Max pull | 7,578 lbs 3437 kg |
| Gear 2H used for pull test. | |
